The products of Shanghai micro powder technology are widely used in various industries of modern industry, such as metallurgy, building materials, chemical industry, mining, papermaking, ceramics, plastics, composite materials, rubber and coatings.
2022-07-04 15:08:27 Micro Powder Technology
| Appearance | The color is changeable, with white, light yellow, light gray, black and green, the strip is white, opaque, smooth to the touch and sticky. |
| Hardness | 2-2.5 |
| Specific Gravity | 1-2.3 |
| High Temperature Resistance | Under the high temperature of 350 degrees, the structure does not change, and the high temperature resistance reaches 1500-1700 degrees |
| Adsorption | Absorbs more than 150% of its own weight in water |
Sepiolite powder has good adsorption, light weight, high temperature resistance, good plasticity, good insulation and high salinity resistance.
Sepiolite Powder
Sepiolite is one of the most widely used mineral raw materials in the world.
Because of the properties of sepiolite, it is more widely used when it is processed into powder.
Sepiolite grinding mill machines are the key equipment for processing sepiolite mineral sand powder.
The following 4 kinds of sepiolite grinding mills are introduced.
According to the fineness of the processed sepiolite powder from low to high, they are: coarse grinding mill, Raymond grinding mill, ultra-fine grinding mill, and ultra-fine vertical grinding mill.
European version coarse powder mill
Maxing Feeding Size: 80 mm
Ouput Size: 0-3 mm
Capacity: 8-100 t/h
Advantages: European Version Coarse Grinding MIll is generally used after jaw crusher, impact crusher or hydraulic cone crusher.
Because the feeding particle size of European version coarse grinding is between 30-50mm, and the discharging particle size is adjustable in the range of 0-3mm, 0-5mm and 0-8mm.
The production capacity can reach up to 100 tons per hour. Uniform discharge and considerable output.
YGM High Pressure Raymond Roller Grinding Mill
Maxing Feeding Size: 40 mm
Ouput Size: 613-33 micron (35-400mesh)
Capacity: 1-25 t/h
Applicable materials: Calcium carbonate, limestone, kaolin, limestone, calcite, marble, talcum, barite, gypsum, dolomite, bentonite mud, mica
Advantages: Raymond mill is a cost-effective fine powder processing equipment. Easy to operate and efficient.
HGM Ultrafine Powder Grinding Mill
Maxing Feeding Size: 20 mm
Ouput Size: 74-5 micron (150-2500 mesh)
Capacity: 0.5-45 t/h
Applicable materials: Calcium carbonate, limestone, kaolin, limestone, calcite, marble, talcum, barite, gypsum, dolomite, bentonite mud, mica, etc.
Advantages: HGM ultra-fine grinding is very different from Raymond grinding in structure. It adopts a multi-ring, layered grinding structure. Due to its multi-ring, multi-roller structure, it is possible to process finer powders and at the same time be more efficient.
CLUM Ultrafine Powder Vertical Roller Mill
Maxing Feeding Size: 10 mm
Ouput Size: 74-5 micron (400-3000 mesh)
Capacity: 0.5-5.5 t/h
D97 < 4μm
D50 < 2μm
Applicable materials: calcite, marble, limestone, dolomite, barite, talc, kaolin, wollastonite, gypsum, feldspar, pyrophyllite etc.
Advantages: Compared with HGM series ultra-fine mill, CLUM series ultra-fine vertical mill produces higher ultra-fine powder content, better powder particle size, less impurities, and higher ultra-fine powder output. It is more suitable for industries with high requirements on powder.
1. The large pieces of sepiolite ore are transported to the raw material warehouse by special vehicles, and then the materials are sent to the jaw crusher by forklifts/manually for crushing, and crushed to be smaller than the maximum feed size of the pulverizer
2. The sepiolite ore crushed by the crusher is lifted by the elevator to the storage hopper, and the storage hopper is discharged and then fed to the host by the feeder evenly
3. During the grinding process of the mill, the qualified products are screened by the screening system and then enter the collector through the pipeline. After collection, they are discharged through the discharge valve to be the finished product. The unqualified products fall into the main machine and re-grind.
4. The fine sepiolite powder ground by the grinding rollers of the pulverizer flows into the blower through the purified air flow through the residual air duct above the dust collector. The powder with qualified fineness passes through the grading rotor blade on the top of the powder mill and enters the pulse (cloth bag) dust collector through the air duct, and is packed in the next step.
